Ultra slow chassis build

Well this all started many many moon's ago over a drunk'in conversation down at K.O.H. and the ball was set in a very very slow moving roll. the main thing's i wanted was a chassis that i could beat the shit out of and never worrie about it. i decided to go with cromo mainly cuz i could get a stupid good deal on it. this build started off shooting for the moon and since i have two teen age boy's it has been pulled way back.........waaay back. this whole build is not a priority to me and i play with it as time and money permit's. my wife and I and all about our family and we spend a ton of time with our boy's. it's not uncommon to be at somesort of a sport event 7 day's a week between games and practices.

Anyway's the main chassi is 1 3/4 .120 wall cromo and a mix of 1 1/4 and 1 1/2 here and there. the biggest concern's for me was that i had enough room for my fat ass to be comfy all day long. i bought a truck load of tube around 280 feet and started hoarding parts. the list of junk as follow's

Chassis spec's
all cromo (had to be Tig welded that was the deal I made to the guy I got the tube from )
fit for a fat guy
110 w/b
54 inches wide
TC FJ40 hood and grill

DRIVETRAIN SPECS
6.0 LS engine
Mast motorsports Head's
custom ground cam by Erson
hex adjust timming set
Morel lifter's that get rid of the gay plastic insert's
F.A.S.T. truck intake for 102mm throttle body
Badass rocker's
custom built stepped header's by Paul Barrett
built TH400 trans
3.8 Atlas case
narrowed Dana 60 front
14 Bolt rear with C&C hub's
PRP low back Comp fat boy seat's
FSR Dual pass radiator,trans cooler, engine oil cooler and p/s cooler
22 Gallon fuel cell
2.5 7075 lower link's
2" upper's
1.250 heim's
14" Bilstein coilover's

I found a few pics of old progress and parts so here you go

SEAT'S PRP COMP LOW BACK'S WITH POCKET'S AND ADJUSTABLE HEAD REST


HEAD'S





LINK'S LOWER



DUAL PASS COOLER'S



F.A.S.T. INTAKE TO FACTORY COMPARO


SHE'S A FISTER


COOL CLEANABLE BILLET OIL FILTER



DID MY OWN ENGINE HARNESS OFF A FACTORY ONE


NOW FOR THE CHASSIS. SINCE WE ALL HAVE SEEN TUBE BENT I WON'T WASTE UR TIME AND FASTFORWARD TO WHEN IT CAME HOME A COUPLE MONTHS AGO





TIG WELDING THE CHASSIS UP



__________________
YUP

Last edited by 1SAWB; June 13th, 2012 at 11:48 AM..
1SAWB is offline   Reply With Quote

Old April 16th, 2012   #2
RADDONKEY
Paid Member

RADDONKEY's Avatar

Join Date: 15 Sep 2006
Posts: 1,624
RADDONKEY is on a distinguished road
Lots of SICK parts coming together.... I cant wait to see it GETTING it someday ...
RADDONKEY is offline   Reply With Quote

Old April 17th, 2012   #3
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
HAD TO REDO THE SUBFRAME THIS WHAT I CAME UP WITH AND IT HAS REMOVABLE CROSSMEMBER'S


FRONT TRUSS IS ALL TACKED UP AND FRONT LOWER LINK'S MOCKED UP







AND BUMP STOP MOCK UP


GOT A KILLER DEAL ON 3 ALTERNATOR KITS THAT IVM MAKES FOR THE LS TO PUT THE ALT IN FRONT OF THE PASS. SIDE HEAD FOR F BODY AND BOUGHT 3 MECHMAN ALT'S FOR THEM. I WILL BE SELLING TWO OF THEM BUT THE ALT'S CAME IN LAST NIGHT



__________________
YUP

Last edited by 1SAWB; October 10th, 2013 at 12:27 PM..
1SAWB is offline   Reply With Quote

Old April 17th, 2012   #4
colonelmustard
Wheeler

Join Date: 02 Apr 2007
Posts: 354
colonelmustard is on a distinguished road
looking good.
__________________
MCCARTHY MOTORSPORTS ...git er done!
colonelmustard is offline   Reply With Quote

Old May 1st, 2012   #5
BIG BLUE
Local shit talker

BIG BLUE's Avatar

Join Date: 04 Aug 2006
Age: 45
Posts: 5,430
BIG BLUE is on a distinguished road
A sick pile of parts. Now you gotta find time in your busy schedule to put it all together!
__________________
I always have the ability to say something to offend someone somewhere.

It's people like you that make me look smart.

I am very sensative to a womans needs...thats why I always buy them kneepads!

Don't you know who I think I am!!!!!
BIG BLUE is offline   Reply With Quote

Old May 9th, 2012   #6
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
SCORED SOME BLANK CHROMO FRONT AXLE SHAFT'S JUST MORE PEICES OF THE PUZZLE



ALSO HAD A HUGE TURBO AND INTERCOOLER GIVEN TO ME THAT WOULD FIT PERFECTLY UNDER THE HOOD BUT NOT SURE I WANNA GO DOWN THIS ROAD. AS MUCH AS I LOVE HORSE POWER NOT SURE I'M READY FOR THIS ONE LOL

ANYWAY'S I HAVE MADE A FEW CHANGES TO THE SUBFRAME AGAIN....... AND THIS ONE HURT THE POCKET BOOK BAD. I ORDERED UP SOME 1 3/4 .188 WALL CHROMO AND WAS INFORMED LAST NIGHT THAT IT WAS ON A HUGE BACK ORDER I MADE A FEW CALL'S LOCALY AND THEY WANTED $25.00 A FOOT I ASKED MY PURCHASING CHICK IF .250 WALL WAS EASIER TO GET AND THEY HAD IT ON THE SHELF SOOOOO THAT SHOULD BE HERE THURSDAY MAYBE TUESDAY AND THE BEST PART IT WAS $18.00 A FOOT STILL SUX BUT OH WELL BETTER THEN $25.00 A FOOT PLUS TAX SO NOW I WILL BE THE PROUD OWNER OF 22 FEET ....UGGGHHHH ONCE THAT GET'S IN THE RE,RE,RE,RECONSTRUCTION WILL BEGIN. I ALSO BOUGHT WAY TO MUCH TUBE FOR THE CENTER CONSOLE/DASH THAT I NEED TO DO
__________________
YUP

Last edited by 1SAWB; October 10th, 2013 at 09:24 AM..
1SAWB is offline   Reply With Quote

Old May 9th, 2012   #7
4xyota
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 29
Posts: 764
4xyota is on a distinguished road
Quote:
Originally Posted by 1SAWB View Post

ANYWAY'S I HAVE MADE A FEW CHANGES TO THE SUBFRAME AGAIN
Third time's the charm Why is it being changed again........
__________________
EIGHT SEVENTY FABRICATION
775-671-0188

RIP Davey Kyle Halabuk
4xyota is offline   Reply With Quote

Old May 10th, 2012   #8
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
NOTHING FIT
__________________
YUP
1SAWB is offline   Reply With Quote

Old June 13th, 2012   #9
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
not much progress but at least more parts are being added to the pile



she sure has a purdy mouth



and look's good on too





Also machined my lower chassis side link tab's



other then that the tube showed up and it has been cut and bent just need to notch and tack it in then on to linking this bitch

I bought some PVC and cut it up to mock the links up and get demension's from there. all look's killer now i can't wait for the real thing

__________________
YUP

Last edited by 1SAWB; October 10th, 2013 at 09:38 AM..
1SAWB is offline   Reply With Quote

Old June 13th, 2012   #10
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
rear atlas support
__________________
YUP

Last edited by 1SAWB; October 10th, 2013 at 09:39 AM..
1SAWB is offline   Reply With Quote

Old June 13th, 2012   #11
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
this is the way i plan on doing the exhaust and header's. i dont care for how close the header is to the valve cover so i figured i would roll it up a bit and make more room. just idea's




__________________
YUP
1SAWB is offline   Reply With Quote

Old June 13th, 2012   #12
boxmuncher
Paid Member

boxmuncher's Avatar

Join Date: 10 Sep 2009
Posts: 743
boxmuncher is on a distinguished road
Looking good!!!!!!!!!!!!!!!!!!!!!
__________________
LOW BUCK CHUCK
boxmuncher is offline   Reply With Quote

Old June 17th, 2012   #13
BIG BLUE
Local shit talker

BIG BLUE's Avatar

Join Date: 04 Aug 2006
Age: 45
Posts: 5,430
BIG BLUE is on a distinguished road
Talking with the guys at Atlas I was told that rear support ring is only advisable on a tube chasis as it will break the rear of the tranny off on a rig with any sort of flex. Everything is coming together so nice!
__________________
I always have the ability to say something to offend someone somewhere.

It's people like you that make me look smart.

I am very sensative to a womans needs...thats why I always buy them kneepads!

Don't you know who I think I am!!!!!
BIG BLUE is offline   Reply With Quote

Old June 18th, 2012   #14
POOR BOY
HARDCORE WEB WHEELER!!!

POOR BOY's Avatar

Join Date: 05 Apr 2007
Posts: 1,850
POOR BOY is on a distinguished road
whos support ring did you use?
__________________
friends dont let friends drive bulldozers ripped on acid
POOR BOY is offline   Reply With Quote

Old June 18th, 2012   #15
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
Quote:
Originally Posted by POOR BOY View Post
whos support ring did you use?
THAT ONE WAS THE ROARK FAB SUPPORT. HE HAD A KILLER SALE ON PIRATES FOR THEM. COOL GUY TOO
__________________
YUP
1SAWB is offline   Reply With Quote

Old June 24th, 2012   #16
MR.ROCKAPE
BANNED

MR.ROCKAPE's Avatar

Join Date: 04 Aug 2006
Age: 15
Posts: 12,988
MR.ROCKAPE is on a distinguished road
Quote:
Originally Posted by BIG BLUE View Post
Talking with the guys at Atlas I was told that rear support ring is only advisable on a tube chasis as it will break the rear of the tranny off on a rig with any sort of flex. Everything is coming together so nice!
I think using that mount keeps you from breaking tranny housings!!! Im using a very similar mount like he has and dont use the foot on the bottom of the adapter at all....the rear atlas support ring mimics the way the factory mounts stuff in a triangle (2 fr motor mounts and a center mounted trans ...) this allows some flex so hard parts dont break...

This is just my opinion.... and my shit is never gonna break since it never gets wheeled!!!
__________________
PROOF!!! THAT TALKIN SH!T ON THE INTERWEB CAN MAKE ME FAMOUS!!!!

MY VIDEO!!!--->ITS NEW!!!!
http://www.youtube.com/watch?v=vNVguvNE7qc

Quote:
Originally Posted by Lance View Post
Time and time again you prove you are the biggest idiot on Pirate4x4. God you're a fucking clown.
MR.ROCKAPE is offline   Reply With Quote

Old June 24th, 2012   #17
MR.ROCKAPE
BANNED

MR.ROCKAPE's Avatar

Join Date: 04 Aug 2006
Age: 15
Posts: 12,988
MR.ROCKAPE is on a distinguished road
Hey sheldon...looks like you chickened out on the single sheer upper link mounts!!!

Looks like alot of bling parts....you know its only 38.3% done right? They look close but all the little stuff just eats time!!!
__________________
PROOF!!! THAT TALKIN SH!T ON THE INTERWEB CAN MAKE ME FAMOUS!!!!

MY VIDEO!!!--->ITS NEW!!!!
http://www.youtube.com/watch?v=vNVguvNE7qc

Quote:
Originally Posted by Lance View Post
Time and time again you prove you are the biggest idiot on Pirate4x4. God you're a fucking clown.
MR.ROCKAPE is offline   Reply With Quote

Old June 25th, 2012   #18
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
THATS TRUE... I DID GET THE NEW NEW NEW NEW NEW SUB FRAME TACKED IN AND I AM SOOO MUCH HAPPIER WITH IT. BEEN BUSY AS HELL WITH KID'S AND SPORTS. FEEL LIKE I DON'T EVEN HAVE TIME TO BREATH ANYMORE
__________________
YUP
1SAWB is offline   Reply With Quote

Old June 26th, 2012   #19
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
Here are a couple pics of the subframe. while waiting for the ride to warm up this morning i took a few pics





AND ROCKAPE HELL NO I'M NOT DOING THE EVIL SINGLE SHEER UPPER.....I OVER DO EVERYTHING
__________________
YUP

Last edited by 1SAWB; October 10th, 2013 at 09:51 AM..
1SAWB is offline   Reply With Quote

Old June 26th, 2012   #20
MR.ROCKAPE
BANNED

MR.ROCKAPE's Avatar

Join Date: 04 Aug 2006
Age: 15
Posts: 12,988
MR.ROCKAPE is on a distinguished road
Im glad you lost the windshield bars to upper link mount tubes that are a few posts up.... it looked a little sketchy....but then again....mine are all single sheer uppers!!!
__________________
PROOF!!! THAT TALKIN SH!T ON THE INTERWEB CAN MAKE ME FAMOUS!!!!

MY VIDEO!!!--->ITS NEW!!!!
http://www.youtube.com/watch?v=vNVguvNE7qc

Quote:
Originally Posted by Lance View Post
Time and time again you prove you are the biggest idiot on Pirate4x4. God you're a fucking clown.
MR.ROCKAPE is offline   Reply With Quote

Old June 26th, 2012   #21
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
That wasn't mine......just header and exhaust ideas. That was a jesse chassis someone built
__________________
YUP
1SAWB is offline   Reply With Quote

Old June 26th, 2012   #22
MR.ROCKAPE
BANNED

MR.ROCKAPE's Avatar

Join Date: 04 Aug 2006
Age: 15
Posts: 12,988
MR.ROCKAPE is on a distinguished road
Quote:
Originally Posted by 1SAWB View Post
That wasn't mine......just header and exhaust ideas. That was a jesse chassis someone built


its good to see you stopped trying to get crazy with the subframe and just did what most people do....simple and effective!!! the plus to your frame being wider, is that those subframe tubes can go straight up and down...mine actually flare out for more room in the belly to fit things.....
__________________
PROOF!!! THAT TALKIN SH!T ON THE INTERWEB CAN MAKE ME FAMOUS!!!!

MY VIDEO!!!--->ITS NEW!!!!
http://www.youtube.com/watch?v=vNVguvNE7qc

Quote:
Originally Posted by Lance View Post
Time and time again you prove you are the biggest idiot on Pirate4x4. God you're a fucking clown.
MR.ROCKAPE is offline   Reply With Quote

Old June 27th, 2012   #23
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
THE LAST ONE WASN'T MY DESIGN. THIS ONE IS. I DID A TON OF RESEARCH AND TALKING TO GUY'S IN THE KNOW AND FIGURED THIS IS IT. I DID PICK UP SOME EXTRA ROOM AND IF AND WHEN I GET TIME I'LL FINISH OFF THE FRONT SUSPENSION AND MOVE TO THE REAR
__________________
YUP
1SAWB is offline   Reply With Quote

Old July 16th, 2012   #24
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
oldest boy got a concussion this weekend at football camp so i spent some time in the garage mainly cleaning but worked on the engine skid. originally it was to have a 180* bent tube but with the new subframe that wasnt going to work which is fine it was kinda ugly reminded me of Umfoofoo with a lip plate lol

this is what i came up with







And the finished template
of course it will have some speed holes to lighten it up and make it look cooler and hope that it helps cool the pan too. the bottom will also be covered in uhmw shit. i also plan on putting some more attaching points to the motor mounts and in the flat area more cross pieces to strengthen it up
__________________
YUP

Last edited by 1SAWB; October 1st, 2012 at 12:07 PM..
1SAWB is offline   Reply With Quote

Old July 16th, 2012   #25
Sierra Valley
HARDCORE WEB WHEELER!!!

Sierra Valley's Avatar

Join Date: 05 Aug 2006
Posts: 3,745
Sierra Valley is on a distinguished road
Looks pretty stout
Sierra Valley is offline   Reply With Quote

Old July 17th, 2012   #26
BIG BLUE
Local shit talker

BIG BLUE's Avatar

Join Date: 04 Aug 2006
Age: 45
Posts: 5,430
BIG BLUE is on a distinguished road
Im not sure I agree. My cardboard skidplate was kinda weak and the first water crossing it fell off. I think the design is good but chose some different material.
__________________
I always have the ability to say something to offend someone somewhere.

It's people like you that make me look smart.

I am very sensative to a womans needs...thats why I always buy them kneepads!

Don't you know who I think I am!!!!!
BIG BLUE is offline   Reply With Quote

Old July 17th, 2012   #27
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
DAMN IT MAN AND I WAS GOING FOR THE SUPER DUPER LIGHT WEIGHT OPTION TOO WHAT TO DO


THE NEXT TWO THING'S IM WORKING ON IS A PIECE TOWARDS THE CROSS MEMBER THATS REMOVABLE SO I CAN GET THE LOWER LINK BOLTS OUT I DREW SOMETHING UP NOW IM JUST THINKING ON IT... LAST NIGHT I MADE A TEMPLATE FOR A FRONT OUTPUT SUPPORT ON THE ATLAS.
__________________
YUP

Last edited by 1SAWB; July 17th, 2012 at 08:35 AM..
1SAWB is offline   Reply With Quote

Old July 17th, 2012   #28
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
i forgot to mention above that the Umfoofoo lip plate engine skid didn't give me much room around the front diff yoke and i didn't much care for that it looked like atride height it would be even with the yoke and maybe .250 of clearance. this design gives me soooo much more room
__________________
YUP
1SAWB is offline   Reply With Quote

Old August 6th, 2012   #29
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
NOTHING NEW AND EXCITING PLAYED A LITTLE BIT WITH IT AND MOVED A FEW THING'S AROUND. FOOTBALL STARTED HERE FOR BOTH MY BOY'S SO I'LL BE DOING THAT TILL OCTOBER THEN I GET A WHOLE 10 DAYS OFF THEN WRESTLING START'S HONESTLY WOULDN'T CHANGE IT FOR THE WORLD

ON A SIDE NOTE I SCORED THESE LAST WEEK
__________________
YUP

Last edited by 1SAWB; October 1st, 2012 at 12:08 PM..
1SAWB is offline   Reply With Quote

Old August 20th, 2012   #30
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
MORE PCS OF THE PUZZLE SHOWED UP SIDE PCS OF THE ENGINE SKID 3/16 AND 4130



THEY FIT PERFECT IN MOCK UP TOO JUST ONE SMALL ADJUSTMENT
__________________
YUP

Last edited by 1SAWB; October 10th, 2013 at 09:53 AM..
1SAWB is offline   Reply With Quote

Old August 30th, 2012   #31
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
Small Update spent a small fortune on NI99 rod ( cough $110.00 a lbs ) but I paid less then half that and I also bought 10 lbs of filler rod for the chassis for a deal that I couldn't pass up.. like close to the amount I paid for 1lbs around here now if my life would slow down I might be able to make some more forward progress



I did manage to go out a mock up the engine skid side plates and they fit near perfect. I do need to open up the bolt hole for the lower link a bit but other then that it's dead on. now I need to drill the side hole's where it attached to the block. a few months ago I bought a set of metric transfer screws so that will go quick. Also getting the brackets for the front axle cut out so the front should be done very soon.....time permitting
__________________
YUP

Last edited by 1SAWB; October 1st, 2012 at 11:55 AM..
1SAWB is offline   Reply With Quote

Old September 24th, 2012   #32
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
GOT MY ARP HEAD STUDS,MAIN STUDS AND ROD BOLTS IN ....IT'S LIKE PORN


]

I DID GET A LIL SIDE TRACKED ON THIS LIL GEM









SHE'S A 67 F-100 SHORT BED 2X WITH A MIGHTY 240 6 CYL AND A 3 ON THE TREE.
THIS LIL TRUCK GET'S JUST OVER 20 MPG WHICH SAVES ME AROUND $20.00 A WEEK IN FUEL SO FAR. AND IT HAS 3.70 REAR GEAR'S I PLAN ON JUST DRIVING THIS THING AND MAKE IT A CLEAN DRIVER/ CRUISER. SLAM IT ON THE GROUND WITH A CROWN VIC FROM SUSPENSION AND IRS REAR
__________________
YUP

Last edited by 1SAWB; October 1st, 2012 at 11:56 AM..
1SAWB is offline   Reply With Quote

Old September 24th, 2012   #33
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
IM THE 3RD OWNER ON THIS BUT THE LAST GUY ONLY HAD IT 6 MONTHS OR SO. IT'S SUPER CLEAN INSIDE AND OUT THE ONLY RUST IS THE TYPLICAL FENDER RUST AND I ALREADY GOT THE DRIVER SIDE FENDER FOR IT THEN IT GET'S PAINTED

__________________
YUP

Last edited by 1SAWB; October 1st, 2012 at 11:59 AM..
1SAWB is offline   Reply With Quote

Old November 8th, 2012   #34
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
Finally got around to working on the front truss and bracket's. now that I have a 1.5 week break from sports with my boy's. The lower link's where bugging the crap out of me and how they seemed unsupported, so i looked around and found some idea's but Rockapes design in the pass.side still appealed to me the most. I do wish they where angled but not a big deal. I made some templates and had the drafts man here at work draw them up in CAD then I ask Jesse to cut them out. All in all very happy with the out come

pass. side upper support. i like how it ties into the tube and cast to support the hell out of the tab's




both straight on


Lower side


Then the driver side pretty normal but I notched for the truss


And finally the truss back on...this was a huge pain in the ass to fit it but I got it


closer shot pass


top


driver side


top


Huge thanks to Mr. Haines for letting me bounce idea's off him and for cutting out my junk. Now onto welding
__________________
YUP
1SAWB is offline   Reply With Quote

Old November 8th, 2012   #35
RADDONKEY
Paid Member

RADDONKEY's Avatar

Join Date: 15 Sep 2006
Posts: 1,624
RADDONKEY is on a distinguished road
Sweet, looks good man !!
RADDONKEY is offline   Reply With Quote

Old November 9th, 2012   #36
MR.ROCKAPE
BANNED

MR.ROCKAPE's Avatar

Join Date: 04 Aug 2006
Age: 15
Posts: 12,988
MR.ROCKAPE is on a distinguished road
Damn.... Your rig is gonna weigh 6500 lbs! I like the truss, hopefully it doesnt hurt your uptravel or make your rig tall. Your chassis design like mine almost needs a step up in the front for axle uptravel.

Looks like your making progress! Thats a good thing.
__________________
PROOF!!! THAT TALKIN SH!T ON THE INTERWEB CAN MAKE ME FAMOUS!!!!

MY VIDEO!!!--->ITS NEW!!!!
http://www.youtube.com/watch?v=vNVguvNE7qc

Quote:
Originally Posted by Lance View Post
Time and time again you prove you are the biggest idiot on Pirate4x4. God you're a fucking clown.
MR.ROCKAPE is offline   Reply With Quote

Old November 9th, 2012   #37
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
THE CHASSIS DOES KICK UP IN THE FRONT AND ALSO NARROW'S. ROUGH MEASUREMENT'S IT LOOKS LIKE WITH 6 INCHES OF UP TRAVEL IT WILL HAVE RIGHT AT 1 INCH OF CLEARANCE BETWEEN TRUSS AND THE TUBE WHEN ON THE BUMPS. OVERALL HEIGHT WILL BE 73-74 TO THE TOP OF THE CAGE AND 20 INCHES OF BELLY WITH 40'S. THE TRUSS IT SELF DOESNT WEIGH THAT MUCH MAYBE A COUPLE POUND'S BUT I DO GO OVERBOARD ON EVERYTHING SO WHY NOT
__________________
YUP
1SAWB is offline   Reply With Quote

Old November 13th, 2012   #38
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
Well since last weekend was basicly my last free weekend I went out and worked on it a bit more. I finished fine tuning the truss then tack welded it all together to double check everything once it's under the chassis also went down and bought more link material ( pvc ) and made the other two links to be sure how it looked and worked good. also cut out some quick .125 tabs to mock up the upper's. I knew the motor mounts I whipped up would be tight but once everything was in I'm not happy with them so I'm redoing them now. I've drawn up a few different designs but none of them do it for me so here are more pics










still playing with the motor mounts
__________________
YUP

Last edited by 1SAWB; October 10th, 2013 at 10:24 AM..
1SAWB is offline   Reply With Quote

Old November 13th, 2012   #39
MR.ROCKAPE
BANNED

MR.ROCKAPE's Avatar

Join Date: 04 Aug 2006
Age: 15
Posts: 12,988
MR.ROCKAPE is on a distinguished road
I got a feeling you are gonna be offsetting that engine to the drivers side.Driveline,starter and exhaust clearance becomes a problem even with extra room on the passengers side for it.

Headers are pretty much needed to be on the engine at mockup,unless you are building them laast to clear stuff.
__________________
PROOF!!! THAT TALKIN SH!T ON THE INTERWEB CAN MAKE ME FAMOUS!!!!

MY VIDEO!!!--->ITS NEW!!!!
http://www.youtube.com/watch?v=vNVguvNE7qc

Quote:
Originally Posted by Lance View Post
Time and time again you prove you are the biggest idiot on Pirate4x4. God you're a fucking clown.
MR.ROCKAPE is offline   Reply With Quote

Old November 13th, 2012   #40
BIG BLUE
Local shit talker

BIG BLUE's Avatar

Join Date: 04 Aug 2006
Age: 45
Posts: 5,430
BIG BLUE is on a distinguished road
Looking good. Making some nice progress.
__________________
I always have the ability to say something to offend someone somewhere.

It's people like you that make me look smart.

I am very sensative to a womans needs...thats why I always buy them kneepads!

Don't you know who I think I am!!!!!
BIG BLUE is offline   Reply With Quote

Old November 14th, 2012   #41
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
It does look tight but the diff yoke and the case yoke are not inline. i have yet to measure it but i would guess the diff side is 3 inches toward the middle compared to the case. the diff yoke is very close to the oil pan but plenty of room. i'm sure i will be running a 2 pcs front drive line. i think i might have time this weekend to play with this again i do plan on building exhaust after it's all in. it will be one of two way's. up and forward header's like for turbo car's then "Y" it together in the front and then run it back...or up and back header's ontop of the cover "kinda" and "Y" it and go down the back of the bell housing and into the muffler. we will soon find out i should get my 14 bolt rear this week and then it's rear mock up
__________________
YUP
1SAWB is offline   Reply With Quote

Old November 14th, 2012   #42
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
Quote:
Originally Posted by MR.ROCKAPE View Post
I got a feeling you are gonna be offsetting that engine to the drivers side.Driveline,starter and exhaust clearance becomes a problem even with extra room on the passengers side for it.

Headers are pretty much needed to be on the engine at mockup,unless you are building them laast to clear stuff.
I do have an in for header's.. a long long time buddy of mine build's header's for super stock, pro stock and alot of NMRA guy's for a living and he already volunteered to build some. good thing is that once a year his whole family goes to Tahoe for vacation and he said he would just cruise over a couple day's
__________________
YUP
1SAWB is offline   Reply With Quote

Old December 20th, 2012   #43
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
well it's been a little bit but here we go.... i had my storage broken into and a ton of shit stolen which included my seats and some other stuff for the buggy so now i have taklen a couple steps back. i have decided to change it up a bit. the main change i made was to the upper links from aluminum to steel. mainly this will now allow me to link the toyota with the aluminum i had for the upper and the remaining steel material for the upper's on the yota too so anyways i was also thinking of mounting the shock's on the lower link but now honestly i could care less anyways here is a few pics of the new shit

2" .250 wall cromo upper's ....yeah i know over kill but hey that's how i roll JACK !!


and possible rub rail for the chassis. it's 4130 solid only down fall is its 1.125 o/d
but it was free

for now that is all


in closing fuck theives in the ass with a freight train
__________________
YUP

Last edited by 1SAWB; April 10th, 2013 at 09:15 AM..
1SAWB is offline   Reply With Quote

Old December 26th, 2012   #44
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
GOT ALL THE UPPER LINK'S TACKED TOGETHER AND THE NEW LINK TABS AND MOUNTS IN PLACE. COULD BE A ROLLER NOW BUT.....................IT'S NOT
__________________
YUP
1SAWB is offline   Reply With Quote

Old February 20th, 2013   #45
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
NOT ALOT OF PROGRESS. BEEN RUNNING LIKE A WILD MAN. OLDEST JUST FINISHED BASKETBALL AND TWO DAYS LATER STARTED TRACK. HE KICKED ASS. HE SET A GOAL OF 200 POINTS THIS YEAR AND ENDED UP SCOREING 212 IN 21 GAMES. MY YOUNGEST HAS BEEN DOING WRESTLING AND IS JUST KILLING EVERYONE THIS YEAR. LAST YEAR HE HAD A COUPLE KIDS THAT HE JUST COULDNT BEAT. WELL THIS YEAR HE IS KICKING THERE ASS COME TO FIND OUT ONE KID WAS RANKED 3RD IN THE NATION LAST YEAR AND ANOTHER WAS 5TH IN THE NATION. THE 5TH IN THE NATION KID'S DAD MADE THE MISTAKE IN TELLING ME HE HAS NEVER BEEN PINNED IN WRESTLING EVER....WELL THAT CHANGED QUICKLY HE WAS PINNED IN THE FIRST ROUND ...CRYING AND SHIT...LOL ANYWAYS SINCE WE SEEM TO WRESTLE TO SAME KIDS OVER AND OVER HE OWRKED ON NEW MOVES AND WE DECIDED TO TAKE HIM TO CALIFORNIA. WE HEARD ALL THE BADASS' ARE THERE AND THEY HAVE BEEN WRESTLING 3 MONTHS LONGER AND IT WAS TIEM FOR THE KID TO GET HIS ASS KICKED. WENT TO THE FOLKSTYLE CHAMPIONSHIPS FOR CALIFORNIA AND HE CLEANED HOUSE WITH ALL FIRST ROUND PINS. THEN A COUPLE WEEEKS AGO WE TOOK HIM TO VACAVILLE FOR THE ST. VALENTINES DAY MASSACRE. WE WHERE TOLD THE BADDEST OF THE BAD ASS KIDS SHOW UP HERE AND HE TOOK 1ST .AND WAS BUMPED UP TO 200LBS CLASS. ANYWAYS STARTING THIS WEEK I AM NOW 7 DAYS A WEEK FOR WRESTLING MIDDLE SCHOOL IS 5 DAY A WEEK PRACTICES WITH SATURDAY MATCHES. CLUB WRESTLING IS 3 DAYS A WEEK PRATICE IN CARSON AND SUNDAY WRESTLING NOT TO MENTION WE TAKE HIM TO THE BEST COACH HE'S HAD HARVEY'S HOUSE FOR A LIL TUNE UP OK ENOUGH OF THAT HERE IS A FEW PICS OF THE KID AND THEN ONTO CHASSIS SHIT

VACAVILLE


FOLKSTYLE STATE CHAMPIONSHIPS
THE BOY WITH ANOTHER LIL BADASS LIL HARVEY WE OWE LIL SHELDON'S SUCCESS ALL TO BIG HARVEY IN MY MIND. HE WORKS WELL WITH SHELDON

OK NOW ONTO THE COOL SHIT

I WANTED A REAR TRUSS THAT WENT FROM FLANG TO FLANG. I COULDNT FIND ONE THAT WAS EXACTLY WHAT I WANTED AND WHEN I DID THE PRICE MADE MY ASS PUCKER. SO I ORDERED UP THE RUFF STUFF TRUSS AND PROMTLY STARTED CUTTING IT UP TO MAKE WHAT I WANT


AND THE PINION SUPPORT AND SHOVEL...LOL


I REORDERED NEW SEAT'S AND I EXPECT TO HAVE THEM IN A COUPLE WEEK'S

THE LOWER FRONT LINKS ARE STILL AT KICK ASS OFFROAD WAITING FOR THEM TO BE FINISHED

I ORDERED UP A BALLISTIC 14 BOLT SHAVE KIT AND A PILE OF OTHER CRAP THAT SHOULD BE HERE THIS WEEK.

GEARS,REAR ARB,CROMO'S AND ALL THE OTHER AXLE RELATED STUFF IS IN THE WORK'S AS WE SPEAK
__________________
YUP

Last edited by 1SAWB; March 15th, 2013 at 11:56 AM..
1SAWB is offline   Reply With Quote

Old February 22nd, 2013   #46
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
MORE TOYS SHOWED UP NOW IF I CAN JUST MAKE THE TIME :P

SHAVING THE 14 BOLT


AND MY WINCH PLATE


ALSO GOT UPPER LINK TABS SO NOW THE LINK PART WILL BE DONE
__________________
YUP

Last edited by 1SAWB; March 15th, 2013 at 12:00 PM..
1SAWB is offline   Reply With Quote

Old March 4th, 2013   #47
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
TOOK THE BOY TO THE IRONMAN THIS PAST WEEKEND IN RENO. THE TOURNAMENT YOU WRESTLE ALL THREE STYLE'S FOLKSTYLE, FREESTYLE AND GRECO. NORMALLY IF YOU WIN ALL THREE IT'S CALLED A TRIPLE CROWN. IN THE PAST THE RARE TIME THAT A KID DOES THIS THEY NOT ONLY GET THEIR MEDAL'S BUT THEY ALSO GET A TROPHY.....WELL WE WENT UP FRIDAY NIGHT AND STAYED THE NIGHT TO BE SURE THE BOYS (LIL HARVEY AND SHELDON II ALONG WITH MY WIFE, BIG HARVEY AND HIS WIFE DANA) WHERE RESTED. WE GOT UP AND HEADED IN FOR WEIGHT IN'S AND BOTH BOY'S WHERE PRETTY FLAT. EITHER WAY THEY WENT OUT AND DESTROYED THE COMPETITION AND GOT 1ST PLACE IN GRECO AND FREESTYLE. THE NEXT DAY THEY BOTH WRESTLED FOLKSTYLE AND AGAIN DESTROYED THE COMPETITION AND BOTH GOT A TRIPLE CROWN. THEN WE CAUGHT WIND THAT THERE WOULD BE NO TROPHIES THIS YEAR THAT THE CLUB COULDN'T AFFORD IT....TO HELL WITH THAT I'LL BUY THEM ONE. ANYWAYS AT THE END OF THE DAY OUR CLUB TOOK HOME NOT ONE BUT THREE TRIPLE CROWN CHAMPION'S. IT WAS FREAKING AWESOME CONGRATES TO THOSE BOYS FOR ALL THEIR HARD WORK. COUPLE PICS WE TOOK

SHELDON AND HARVEY HIS MAIN COACH ON THE LEFT AND WILL ON THE RIGHT


AND A PIC OF ALL THREE BOY'S AND THEIR MEDAL'S
LEFT TO RIGHT WILL, BRADY O', SHELDON, LIL HARVEY AND MIKE ALL FROM THE BULLDOGS
__________________
YUP

Last edited by 1SAWB; March 15th, 2013 at 12:03 PM..
1SAWB is offline   Reply With Quote

Old March 15th, 2013   #48
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
SHEEEEWW FINALLY SLOWING DOWN A BIT FOR ME. TOOK THE KID TO STATE FOR WRESTLING AND HE TOOK 1ST IN ALL THREE EVENTS AND THE TRIPLE CROWN AWARD.

CANT BEAT THAT SMILE ;D


AND OF COURSE A PIC WITH HIS COACHES


OK NOW BACK TO OUR REGULARLY SCHEDUALED PROGRAM

NOW THAT "CLUB" WRESTLING IS OVER I HAVE A LITTLE BIT OF TIME AND I MEAN A LITTLE BIT. I FIRST HAD TO DO A LITTLE CLEANING IN THE GARAGE THEN GOT TO WORK.
GOT THE TRUSS FITTED UP

HAD TO BOLT ON THE DIFF COVER TO SEE HOW MUCH WILL BE TAKEN OFF ;D


SIDE SHOT
__________________
YUP
1SAWB is offline   Reply With Quote

Old March 15th, 2013   #49
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
WHAT GOT ME KICKED IN THE ASS WAS THAT MY NEW...NEW SEAT'S SHOWED UP. I PICKED THEM UP MONDAY AFTER WORK AND OF COURSE HAD TO SET THEM IN AND GO FOR A RIDE YEAH I WHEELED THE HAMMER'S THAT NIGHT...MADE ENGINE NOISES AND EVERYTHING



NOW THAT THE DAMN TRUSS IS ON AND THE LOWER'S TACKED IN I MOVED ON TO THE UPPER'S. WHILE ALL INSPIRED I HAD TO START PLAYING AROUND WITH HOW EVERYTHING WOULD FIT

BUMP'S IN,COILOVER CLOSE TO WHERE I THINK I MIGHT WANT IT AND I EVEN PUT THE SWAY BAR IN FOR MOCK UP
__________________
YUP
1SAWB is offline   Reply With Quote

Old March 15th, 2013   #50
1SAWB
HARDCORE WEB WHEELER!!!

Join Date: 05 Aug 2006
Age: 44
Posts: 1,665
1SAWB is on a distinguished road
PICS WITH THE SWAY BAR IN.....GETTING PRETTY TIGHT


QUICK VIDEO OF ME SCREWING AROUND WITH A BRIDGEPORT




WITH ALL THIS MOCKING UP AND ME AND MY O.C.D. AND OVER THINKING EVERYTHING I FOUND THAT THE WINCH PLATE WONT WORK FOR ME IN THE INTENDED STOP BECAUSE IT'S TO NARROW. IM NOW THINKING OF CUTTING THE FRONT OF THE CHASSIS OFF AND MOUNTING THE WINCH BEHIND THE GRILL
__________________
YUP
1SAWB is offline   Reply With Quote
Reply


Currently Active Users Viewing This Thread: 1 (0 members and 1 guests)

Thread Tools
Display Modes

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off

Forum Jump


All times are GMT -7. The time now is 05:34 PM.

Powered by vBulletin® Version 3.8.4
Copyright ©2000 - 2018, Jelsoft Enterprises Ltd.
User Alert System provided by Advanced User Tagging v3.2.4 (Lite) - vBulletin Mods & Addons Copyright © 2018 DragonByte Technologies Ltd.
TRG 2009
